Reel to Card Laminating Machine

Home Products Large Scale Rapid Test Production Automatic Rapid Test Lamination Reel to Card Laminating Machine

Reel to Card Laminating Machine

  • Product Item:Reel to Card Laminator M-NM210
  • reel to card lateral flow test laminator
  • Category:Automatic Rapid Test Lamination
  • Inquiry Send Email

    Description

    Automatic Continuous Reel to Card Laminator M-NM210

    This continuous laminator was developed to meet the need of fully automatic production in laminating process.

    Each material is fed from adjustable spindles through guides and under a pressure capstan roller to assure complete adhesion to the plastic support backing. Numerous options are available allowing the system to support a wide variety of material types like nitrocellulose, conjugate pads, absorbent paper, PE film, etc. The resultant laminated material pass by the conveyor to cut into discrete cards for further processing on other

    Product Features

    1. Standard type suit for uncut sheet width from 60 to 100mm, to laminate components on reel format backing card

    2. It is applicable for laminating all the components of lateral flow rapid test on the backing cards

    3. High precision NC membrane lamination secured by deviation-correction device, the membrane will get through this device which can correct the displacement when pulling and laminating the NC membrane

    4. Adopts Panasonic PLC+optical fiber sensor +stepper motor, to support the equipment to run 7x24hours in the high stability

    5. Simple adjustment by rotating screw rod adjusting wheel, make it easy and convenient to change different products

    6. With artificial intelligence control and automatic photoelectric tracking system, when there is no material coming, it will stop automatically, it only start laminating when there is material coming

    7. Counting function available for the convenience of production management

    8. Touch screen operator interface terminal for simple setup and operation

    9. Flexible to support changing requirements

    10. It is an customized equipment

    Parameter


    Suitable for 1 to 7 rapid test components lamination

    Power:220V/110V, 1500W

    Laminating efficiency:130mm/sec

    Laminating precision: ±0.1mm

    Equipment dimension: 1700*650*1550

    Working platform dimension: customized

    Flexible

    Menu driven operating software

    Customized working platform dimension

    Customized laminating material types


    Video Link:Lateral Flow Test Reel to Card Lamination
