Automatic Sheet Laminating Machine

Home Products Large Scale Rapid Test Production Automatic Rapid Test Lamination Automatic Sheet Laminating Machine

Automatic Sheet Laminating Machine

  • Product Item: Lamination M-NM200
  • Rapid Test Component Laminating Machine
  • Category:Automatic Rapid Test Lamination
  • Inquiry Send Email

    Description

    Automatic Continuous Uncut Sheet Laminator (on Sheet Format Backing Card)M-NM200

    Automatic Continuous Uncut Sheet Laminator (on Sheet Format Backing Card)M-NM200

    This automatic laminator is suitable to laminate multiple components, such as reel format absorbent pad, "max" PE film, NC membrane, sample pad on the sheet format pvc backing card of the lateral flow rapid test, then cut it into discrete cards(eg. 300mm uncut sheets)



    Product Features

    1. Standard type suit for uncut sheet width from 60 to 100mm, length 280 to 310mm

    2. It is applicable for laminating all the components of lateral flow rapid test on the backing cards

    3. High precision NC membrane lamination secured by design of deviation-correction device, the membrane will get through this device which can correct the displacement when pulling and laminating the NC membrane.

    4. Adopts Panasonic PLC+optical fiber sensor +stepper motor, to support the equipment to run 7x24hours iin the high stability

    5. Simple adjustment by rotating screw rod adjusting wheel, make it easy and convenient to change different products.

    6. With artificial intelligence control and automatic photoelectric tracking system, when there is no material coming, it will stop automatically, it only start working when there is material coming

    7. Counting function available for the convenience of production management

    8. Touch screen operator interface terminal for simple setup and operation

    9. Flexible to support changing requirements



    Parameters

    Power:220V/110V, 1600W
    Efficiency:600pcs/hour
    Laminating precision:±0.1mm
    Dimension:1700*600*1430



    Flexible

    1. Menu driven operating software.

    2. Customized working platform dimension.

    3. Customized laminating material types.
