Raw Materials Guillotine Cutter

Home Products Large Scale Rapid Test Production Raw Materials Cutter Raw Materials Guillotine Cutter

Raw Materials Guillotine Cutter

  • Product Item:Raw Material Cutter QG002
  • Raw Material Guillotine Cutter
  • Rapid Test Component Cutting
  • Category:Raw Materials Cutter
  • Inquiry Send Email

    Description

    Guillotine Cutter for raw materials QG002

    Guillotine Cutter for raw materials QG002

    The Guillotine Cutter QG002 is mainly used to cutting raw materials for lateral flow components, such as absorbent paper, sample pad and conjugated pad.

    Compared with QG001, it is equipped with a longer blade and often used in production to cut A4 paper-sized materials into strips. The special blade has sharp edges, only suitable for cutting soft and crisp texture sheets without glue.

    A flexible operator interface provides quick changes of cut widths and quantities, the programs easily store the parameter and call up at any time. The interface will monitor the current quantities and width. The operator can set the life of the blade. When the life is approaching, the machine will alarm to remind the operator to change the blade.

    Product Features

    1. Quick Stop and Start one button control

    2. Special cutting device structure design, the upper blade and lower blade touching properly without any gap, which can ensure:

    (1) Precisely cut the strip perfectly with clean edge

    (2) Simple to dismantle and change the blade without any complicated adjustment

    (3) Stable running, no parts will be loose in high intensive volume production.

    (4) Easy blade cleaning without dismantling

    3. Simple calibration on operator interface

    4. Safety interlock device, and blade cover

    5. Blade is made of long life alloy made, sharpen or change it every 1million cut

    6. Issues alarm and history records is checkable in the individual interface, solution will be provided immediately by the system

    7. Customized button and interface available for your production convenience

    Parameter

    Power:220V/110V, 500W

    Cutting efficiency:Max400times/min

    Cutting precision: ±0.05mm

    Equipment dimension: 500*500*470mm

    Feeding dimension: Max Sheet Width 300mm,Length no limit

    Flexible

    Menu driven operating software.

    Custom feeding dimension.

    Anti-static device.
